COMPRESSORS

Selecting a Bostitch

Compressor

After spending months in the field working with

professional contractors like you, our mission

was clear: Develop a line of air compressors

that deliver durability, performance and convenience.

Roll cages and skid plates inspired by off-road

trucks, as well as heavier gauge steel base

plates and recessed components, combine to

protect Bostitch

compressors on even the

most hostile job sites.

Patented pump technology, large pumps

and high efficiency motors deliver quality

performance in even the most demanding applications.

Integrated control panels, multiple air outlets

and pull-cord style drain cocks offer the

professional user the ultimate in air

compressor convenience.

Bostitch

Air Compressors…

Proven air quality.

Proven durability.

Proven performance.

Tips to Improve Your Bostitch

Compressor Performance

Air

For best results, use regulated

air and never use more air

pressure than is necessary to

drive the fasteners. Most

Bostitch

tools operate best

between 80 and 95 PSI. If the

fastener sets well at 85 PSI, use

that pressure. Keep the airline

as short as possible to prevent a

pressure drop from the Bostitch

compressor to the tool.

Water

As Bostitch

Compressors

operate, they generate

condensation which needs to be

drained regularly. In very hot

humid weather, you may need to

drain it several times each day.

In dryer climates, once per day

should be enough. Open the

drain valves near the bottom of

the tank while the tank is under

pressure to relieve moisture.

Then close the valve carefully.

Never twist the valves with pliers.

Just tighten them until the air

stops leaking.

Electric

Don’t use an extension cord to

run your Bostitch

compressor if

at all possible, instead use a

longer airline. If you must

operate your Bostitch

compressor in a remote area,

use a heavy gauge extension

cord as follows.

25 Feet - Use 14-Gauge Cord

50 Feet - Use 12-Gauge Cord

100 Feet - Use 10-Gauge Cord

150 Feet - Use 8-Gauge Cord

Oil

Put a few drops of oil in the air

fitting of your Bostitch

Tool

in the morning and then again

in the afternoon. That’s all you

need to keep your Bostitch

Tool running smoothly. And,

always use only approved

non-detergent oil that comes

with your Bostitch

Tool.

Not all Bostitch

products

require oil.

RECOMMENDED TOOL CAPACITY COMPRESSOR APPLICATION GUIDE

CAP 1560-A CAP1545PT-OF CAP1545PT-OL

CAP2045ST -OL CAP1580WB

CAP5580WB

Sealant Dispenser

Blow Gun

Paint Sprayer

Sandblaster (Cup)

Air B rush

Grease Gun

Impact Wrench

Air Chisel

Sander ( Low Speed)

Sander ( High Speed)

Drill

Ratchet

CAP 1560-A

CAP 154PT-OF

CAP 1545PT-OL

CAP 2045ST-OL

CAP 1580WB

CAP 5580WB

RECOMMENDED

NOT RECOMMENDED

Some of the extreme testing Bostitch® Air Compressors are subjected to during development.

(Do not try this at home. Photo reflects test conditions on a closed course)

Work Safely with Tools, Wear Safety Glasses.
